White, low viscosity, low odor, and good workability. Cures at room temperature when exposed to moisture. Excellent flexibility, adhesive property, electrical insulation, weather resistance, aging resistance, and thermal cycle resistance.
Applications
- Electrical insulation
- Protects leads from mechanical shock
- Bond the sealing surface
- Used in microwave ovens
| Uncured Property | Value |
| Base Resin | Poly(dimethyl)siloxane |
| Color | White |
| Viscosity (cps @ 23℃) | 70000~100000 |
| Cure Speed(Tack Free Time/Full) | 10~35min/24h(≥2mm) |
| Specific Gravity(g/cm3 @ 23℃) | 1.10 |
| Cured property (Measured on cured sheets ~2mm. Cured @ 23±2℃, 50±5%RH for 7 days, tested at 23±2℃) |
Value |
| Operating Temperature Range (℃) | -54 to 210 |
| Hardness (Shore A) (GB/T 531) | 33 |
| Elongation at break (%) (GB/T 528) | 180 |
| Tensile Strength (MPa) (GB/T 528) | 1.5 |
| Shear Strength (MPa) (GB/T 7124 ) | 1.5 |
| Volume resistivity(Ω·cm) (GB/T 1692) | 2.0×10^15 |
