Product Introduction
The FAV-600 is a fully automated inline meter-mixing and dispensing system with a screw pump or double piston pump. Integrated with a CCD vision system, it ensures ±0.03mm dispensing accuracy, ideal for high-volume manufacturing.
FAV-600 Features:
- CCD vision system for position detection with ±0.03mm accuracy.
- Flexible mixing ratio adaptable to different fluid components.
- Large capacity feeding tank for extended production runs.
- High-precision V-valve set for consistent dispensing.
- Inline vacuum system for bubble-free dispensing.
- Intelligent screw feed pump for high-volume production.
- Advanced automation features for efficient operation and cleaning.
FAV-600 Applications:
- Electronics manufacturing: PCB potting, conformal coating, and encapsulation.
- Automotive: Sealing, bonding, and component protection.
- Medical devices: Consistent, precise fluid dispensing.
- Aerospace: High-volume, inline dispensing for complex components.
About Prostech
Prostech Philippines is a one-stop solution provider for specialty materials and equipment across electronics manufacturing, from PCBA to final assembly. Our core material and equipment solutions include:
- PCB Assembly Materials
- Cleaning & Degreaser
- Circuit Board Protection
- Thermal Management Solutions
- EMI Shielding
- General Assembly Adhesives
- Elastomeric Materials
- Process Equipment: Potting & Coating Systems, UV/ Heat Curing, Plasma Treatment, Tape placement automation, and cleaning machines
Technical Added Value to customer
Prostech offers customized material and process equipment solutions with engineering support throughout R&D, production process optimization, and performance validation. Our in-house lab located in Alabang, Muntinlupa is equipped to conduct electronics material testing, application simulation, and adhesive validation, helping customers reduce the need for onsite trials and accelerate implementation.
International Supply Chain Advantage
Regional warehouse hubs across Vietnam, Singapore, Malaysia, and the Philippines ensure cross-border reliable supply. In Philippines PEZA-bonded warehouse located at Lima Industrial Park, Batangas enables Prostech to provide responsive, demand-based delivery and significantly shortens standard lead time for Philippines customers.
Need help selecting the right product or solution?
System General Physical & Electrical Specifications
| Specification | Details |
|---|---|
| Power Consumption | 18kW |
| Power Supply | 380V, 3 Phases, 50Hz Approx. |
| Air Pressure | Clean, Dry Compressed Air 0.5 Mpa – 0.7 Mpa |
| Operating Temperature | -10°C ~ 50°C |
| Humidity | 10 ~ 90% (non-condensation) |
| Net Weight | Approx. 1000Kg |
| Outer Dimension (LxWxH) | Approx. 1500 x 1200 x 1500 mm |
Metermix Modular Specifications
| Specification | Details |
|---|---|
| Mixing Ratio | 1:1 – 10:1 (Programmable) |
| Mixing Accuracy | ±2% |
| Glue-out Speed | 1 g/s ~ 24 g/s |
| Glue-out Accuracy | ±2% |
| Viscosity | 50 ~ 30,000 cps |
| Operation Mode | Manual/ Automatic |
| Mixing Ratio Control | Intelligent Screw Pump/ Dual Piston Pump & PLC |
| Flow Control | Digital Input |
| User Interface | Digital Display |
| Mixing Method | Static Mixing |
| Cleaning Method | Automatic Cleaning |
| Tank Material (A & B) | Stainless Steel |
| Tank Capacity (A & B) | 60L |
| Liquid Level Sensor | Low liquid level/ High liquid level Alarming |
| Tank Stirring | Tank A & Tank B |
| AB Tank Constant Temperature Heating | Available |
| AB Pipe Constant Temperature Heating | Available |
| Glue Filter | Available |
